GOST-Certified Fire Hoses (Model Range 8 to 25) - Including Materials, Pressure Ratings & Customization Options

Detailed Product Data Sheet for 52mm (50mm ID) 1.6 MPa Model 16 and Other Variants: Working Pressure, Burst Pressure, Construction, and Lining Materials

Overview
Parameter
Quick Detail
Applications
Competitive Advantage
Related Products

Overview

This product information sheet provides the complete technical specifications for a range of fire hoses manufactured and tested to meet GOST standards. The detailed parameters for the Model 16 (1.6 MPa) hose and other models in the series are outlined below.

1. General Product Characteristics:

Jacket Fabric & Weave: Options include Double jacket, Thickening jacket, Twill weave, Color Plain weave, Polyester yarn, and Coating.
Lining Material: Various synthetic rubbers and polymers are used, including EPDM, Rubber, PU, PVC, TPR, and TPE.
Durable Hose Type: Designed as a Double rubber or PVC hose for enhanced longevity.
Product Structure: Available in Single Jacket fire hose, Double Jacket fire hose, and Durable hose constructions.
Standard Colors: White, Red, Yellow, Green, Blue, Black.

2. Detailed Model Specifications Table:

Model	Working Pressure	Burst Pressure	Inner Diameter (mm)	Length (m)	Remarks / Lining Materials
8	0.8 MPa	2.4 MPa	25, 40, 50, 65, 100	20~30	PVC, TPR, TPU
10	1.0 MPa	3.0 MPa	25, 40, 50, 65, 100	20~30	EPDM, RUBBER
13	1.3 MPa	3.9 MPa	25, 40, 50, 65, 100	20~30
16	1.6 MPa	4.8 MPa	25, 40, 50, 65, 100	20~30	Special length, outer woven layer, and lining color can be customized according to customer requirements.
20	2.0 MPa	6.0 MPa	25, 40, 50, 65, 100	20~30
25	2.5 MPa	7.5 MPa	25, 40, 50, 65, 100	20~30

3. Key Notes:

The burst pressure is consistently three times the working pressure for all models.
The 50mm inner diameter is the standard equivalent to a common 52mm nominal size.
Customization is available for special lengths, the characteristics of the outer woven layer, and the color of the lining upon request.

Parameter

Product general information：

Place of Origin:	Nantong
Brand Name:	Longtao
Model Number:	LT-H01
Certification:	CE

Commercial terms of products：

Minimum Order Quantity:	200M
Price:	Need to negotiate
Packaging Details:	carton
Delivery Time:	5-30days
Payment Terms:	T/T
Supply Ability:

Quick Detail

MATERIAL OF JACKET	Polyester yarn, rubber
TYPE OF LINER	PVC,RUBBER
NORMAL COLOR OF JACKET	RED, BROWN, BLACK,yellow,customized
NORMAL COLOR OF LINER	RED, BROWN, BLACK,yellow,customized
WORKING PRESSURE	4-50 BAR
BURST PRESSURE	12-150 BAR
SIZES(INSIDE DIAMETER)	19-300 MM
LENGTH PER ROLL	10-100M

Applications

Fire fighting ,Agricultural irrigation,Drainage

Competitive Advantage

We are a professional manufacturer of fire products, thirty years of manufacturing experience and process accumulation make our products excellent quality and durable. It has received wide recognition in both the domestic and international markets.
